Anycubic DLP SLA LCD High-Speed 3D Printer

Anycubic DLP SLA LCD High-Speed 3D Printer

ANYCUBIC Photon Mono 2

The First Choice for Resin 3D Printing Beginners

6.6-inch 4K+ LCD Screen | 2.09L Print Volume | Upgraded LighTurbo Matrix

• Exposure screen: 6.6” monochrome
• Printing accuracy: 4K+ (4,098 x 2,560 px)
• Contrast ratio: 300:1
• Light transmittance: 3.5-4.5%
• Light source: Parallel matrix (LED x 15)
• Printing dimensions: 5.6 x 3.5 x 6.5 in.
• Printing time: >1.5s / layer
• Printing speed: 1.97 in./hr.
• Machine leveling: Manual (4-point)
• Power supply: 48W

ANYCUBIC Photon Mono X2

Following the Classics: Unlimited Creativity

9.1″ 4K HD Screen | Anycubic LightTurbo | Improved Speed & Stability

• Exposure screen: 9.1” monochrome
• Printing accuracy: 4K+ (4,098 x 2,560 px)
• Contrast ratio: 200:1
• Light transmittance: 5.0%
• Light source: Parallel matrix (LED x 24)
• Horizontal resolution: 48 µm
• Printing dimensions: 7.8 x 7.7 x 5 in.
• Printing time: 1.5-3s/ layer
• Printing speed: 2.36 in./hr.
• Machine leveling: Manual (4-point)
• Power supply: 100W

ANYCUBIC Photon Mono X 6Ks

6K and 9-inch Upgrade

9.1 inch 6K screen | 4.76L build volume | Upgraded LighTurbo Matrix

• Exposure screen: 9.1” monochrome
• Printing accuracy: 6K (5,760 x 3,600 px)
• Contrast ratio: 380:1
• Light transmittance: 6.5%
• Light source: Parallel matrix (LED x 24)
• Horizontal resolution: 34 µm
• Printing dimensions: 7.8 x 7.7 x 4.8 in.
• Printing time: ≥1s / layer
• Printing speed: 3.15 in./hr.
• Machine leveling: Manual (4-point)
• Power supply: 80W

ANYCUBIC Photon Mono M5

Details Always On

10.1 Inch 12K | Laser Carving Build Plate | Dual Lead Screw Linear Rails

• Support App control
• Exposure screen: 10.1” monochrome
• Printing accuracy: 12K (11520 x 5120 px)
• Contrast ratio: 480:1
• Light transmittance: 4.7%
• Light source: Parallel matrix (LED x 28)
• Horizontal resolution: 19µm
• Printing dimensions: 8.58 x 7.87 x 4.84 in.
• Printing speed: 1.96 in./hr.
• Machine leveling: Manual (4-point)
• Power supply: 100W

ANYCUBIC Photon Mono M5s

Print Like a Master

10.1″ 12K Screen | Leveling-Free | 3X Faster

• Support App control
• Machine leveling: Leveling-Free
• Exposure screen: 10.1” monochrome
• Printing accuracy: 12K (11520 x 5120 px)
• Contrast ratio: 480:1
• Light transmittance: 4.7%
• Light source: Parallel matrix (LED x 28)
• Horizontal resolution: 19µm
• Printing dimensions: 8.58 x 7.87 x 4.84 in.
• Printing speed: With high-speed Resin: 4.13 in./hr; With general resin: 2.76 in./hr
• Power supply: 100W

ANYCUBIC Photon M3 Max

Large and Extraordinary

14.7L Large Print Volume | 13″ 7K Monochrome Screen | Anycubic Auto Resin Filler

• Support Automatic feeding
• Exposure screen: 13.6” monochrome
• Printing accuracy: 7K (6,480 x 3,600 px)
• Contrast ratio: 450:1
• Light transmittance: 5-6%
• Light source: Parallel matrix (LED x 84)
• Horizontal resolution: 46 µm
• Printing dimensions: 11.8 x 11.7 x 6.5 in.
• Printing time: ≥1.5s / layer
• Printing speed: 2.36 in./hr.
• Machine leveling: Manual (4-point)
• Power supply: 120W

ANYCUBIC Photon D2

One Step Forward

DLP® | High Precision | Premium Experience

• Exposure screen: 5.9” monochrome
• Printing accuracy: 2K (2,560 x 1,440 px)
• Contrast ratio: 1000:1
• Light source: DLP
• Horizontal resolution: 51 µm
• Printing dimensions: 6.5 x 5.1 x 2.9 in.
• Printing time: ≥2.5s / layer
• Printing speed: 1.96 in./hr.
• Machine leveling: Manual (4-point)
• Power supply: 15W

ANYCUBIC Photon Mono 4

Beginning is Stunning

7-inch 10K High-Definition Screen | 2.2L Maximum Print Volume | LighTurbo Light Sourcing System

• Exposure screen: 7″ High-Definition Screen
• Printing accuracy: 10K+ (9024 x 5120 px)
• Light source: Parallel matrix upgrade Light Source
• Printing dimensions: 6.0 x 3.4 x 6.5 in.
• Product Dimensions: 9.1 x 9.3 x 15.4 in.
• Printing speed: ≤2.76 in./hr.
• Machine leveling: Manual (4-point)
• Slicing software: Photon Workshop
• File Transfer: USB
• Maximum print volume: 2.2L
• Net Weight: 4KG

ANYCUBIC Photon Mono 4 Ultra

Outsmart, Outstart

10K High-Precision | Faster Curing | Intelligent-Assist Printing

• Z Axis: Single linear with 20µm accuracy
• Build Platform: Laser engraving aluminum alloy
• Exposure Screen: 7″ monochrome
• LCD Resolution: 10K (9024 x 5120px)
• Light Source: COB Light Source and Fresnel Lens and Factory Algorithm Calibration
• Control Panel: 4.3″ TFT touch-control
• Data Input: USB-A 2.0, WIFI
• Machine Leveling: 4-point manual leveling
• Printing Speed 1: 80mm/h peak speed (Standard Resin 0.1mm layer height)
• Printing Speed 2: 120mm/h peak speed (High Speed Resin 0.1mm layer height)
• Printing Dimensions: 6.04 x 3.42 x 6.48 in. / 153.4 x 87 x 165mm (HWD)
• Product Dimensions: 236mm x 231mm x 430mm / 9.29 x 9.09 x 16.93 in. (HWD)
• Machine Weight: 5KG / 11lb.
• Maximum print volume: 2.2L / 74.4oz.

Wash and Cure 3

• Cleaning Size (With platform): 165 x 100 x 165mm / 6.5 x 3.9 x 6.5 inch
• Maximum Cleaning Size (Without platform): 165 x 100 x 180mm / 6.5 x 3.9 x 7.1 inch
• Maximum Curing Size: Φ160 x 180mm / Φ6.2 x 7.08 inch
• Machine size: 216 x 217 x 310 mm / 8.5 x 8.5 x 12.2 Inches (L x W x H)
• Machine Weight: 2.7 kg / 5.9 lbs
• Suitable Model: Photon Mono 2 / Photon D2

Wash and Cure 3 Plus

• Cleaning Size (With platform): 228 x 128 x 250 mm / 6.5 x 5.0 x 9.8 inches
• Maximum Cleaning Size (Without platform): 228 x 128 x 260 mm / 6.5 x 5.0 x 10.2 inches
• Maximum Curing Size: Φ220 x 260mm / Φ8.7 x 10.2 inch
• Machine size: 312 x 267 x 434mm / 12.3 x 13.8 x 17.1 inches (L x W x H)
• Machine Weight: 5.7 Kg / 12.6 lbs
• Suitable Model: Photon Mono X2 / X 6Ks / M5 / M5s

Wash and Cure Max

• Washing and Curing Size: 300 x 165 x 300mm / 11.8 x 6.5 x 11.8 inches (LWH)
• Machine size: 434 x 434 x 556mm / 17.1 x 17.1 x 21.9 inches (LWH)
• Machine Weight: 13.5 kg / 29 lbs
• Suitable Model: Photon M3 Max
